KM125A Bending Beam Load Cell

MODEL : KM125A

Bending beam load cell, stainless steel construction
10kg…500kg

● Capacities from 10kg to 500kg
● Made of stainless steel, hermetically sealed
● High accuracy, high stability, good reproducibility
● Hermetically sealed, used in harsh industrial environments
● Environmental protection IP67 (IP68 customizable)

Capacity

10kg / 20kg / 30kg / 40kg / 50kg / 75kg / 100kg / 150kg / 200kg / 300kg / 500kg

Applications

● Floor scales, hopper scales, etc
● Silo and tank weighing
● Filling and packaging
● Mobile weighing
● Conveyor belt weighing
● Control and sorting by weight
● Continuous mixing and dosing
● Industrial process control
