KM143C Shear Beam Load Cell

MODEL : KM143C

Shear beam load cell, alloy steel construction
250kg…10t

● Capacities from 250kg to 10t
● Made of alloy steel, easy to mount
● High accuracy, high stability, good reproducibility
● Rugged design, wide range of capacities
● Environmental protection IP67

Capacity

250kg / 500kg / 1t / 1.5t / 2t / 2.5t / 5t / 7.5t / 10t

Applications

● Floor scales, hopper scales, etc
● Silo and tank weighing
● Filling and packaging
● Mobile weighing
● Conveyor belt weighing
● Control and sorting by weight
● Continuous mixing and dosing
● Industrial process control
