KM865A Pin Load Cell | Wägerkraft

MODEL : KM865A

Pin load cell, stainless steel construction
5kN…1250kN

● Capacities from 5kN to 1250kN
● Made of stainless steel, easy to mount
● High accuracy, high stability, good reproducibility
● Wide range of capacities, customizable dimensions
● Rugged design, environmental protection IP67

Capacity

5kN / 10kN / 20kN / 50kN / 100kN / 200kN / 500kN / 1000kN / 1250kN

Applications

● Crane scales
● Overload protection
● Cranes and hoisting devices
● Elevators and wire rope winches
● Hanging weighing systems
● High capacity applications
● Special weighing
● Dynamic force measurement and monitoring
